Cellular Routers

OnCell 5004/5104

Industrial quad-band GSM/GPRS cellular routers

Features and Benefits Industrial Cellular Router

  • Universal quad-band GSM/GPRS 850/900/1800/1900 MHz
  • GuaranLink and dual SIM redundancy for continuous cellular connections
  • Connect to 4 10/100BaseT(X) devices over an integrated VPN
  • Centralize private IP management with OnCell Central Manager
  • DIN-Rail and wall mountable housing
  • 2 digital inputs and 1 relay output (OnCell 5104 only)

Introduction

The OnCell 5004/5104 are high-performance industrial grade cellular routers that allow up to 4 Ethernet-based devices to simultaneously use a single cellular data account for primary or backup network connectivity to remote sites and devices. Both products provide the functionality of a cellular router, firewall, and switch in one device. To ensure zero data lose and on-demand cellular communication, OnCell 5004/5104 are integrated with GuaranLink function. The difference between the OnCell 5004 and OnCell 5104 is that the OnCell 5104 comes with a built-in relay output that can be configured to indicate the priority of events when notifying or warning engineers in the field, and the two digital inputs allow you to connect basic I/O devices, such as sensors, to the cellular network. The OnCell 5004 can be placed on a desktop or wall-mounted, whereas the OnCell 5104 has an IA design and can be attached to a DIN-rail. Both products use 12 to 48 VDC power inputs with a screw-on design for greater reliability, and the Ethernet ports come with 1.5 KV magnetic isolation protection to keep your system safe from unexpected electrical discharges.
