DIN Rail Managed Ethernet Switches

EDS-405A/408A Series

5 and 8-port entry-level managed Ethernet switches

Features and Benefits

  • Command Line Interface (CLI) for quickly configuring majorClick to download 2012 IES Brochure managed functions
  • IPv6 Ready logo awarded (IPv6 Logo Committee certified)
  • DHCP Option 82 for IP address assignment with different policies
  • Support EtherNet/IP and Modbus/TCP protocols for device management and monitoring
  • Compatible with EtherNet/IP and PROFINET protocols for transparent data transmission
  • Turbo Ring and Turbo Chain (recovery time < 20 ms), and RSTP/STP for network redundancy
  • IGMP snooping and GMRP for filtering multicast traffic
  • Port-based VLAN, IEEE 802.1Q VLAN, and GVRP to ease network planning
  • QoS (IEEE 802.1p and TOS/DiffServ) to increase determinism
  • RMON for efficient network monitoring and proactive capability
  • SNMPv1/v2c/v3 for different levels of network management security
  • Bandwidth management to prevent unpredictable network status
  • Port mirroring for online debugging

Introduction

The EDS-405A/408A are entry-level 5 and 8-port managed Ethernet switches designed especially for industrial applications. The switches support a variety of useful management functions, such as Turbo Ring, Turbo Chain, ring coupling, port-based VLAN, QoS, RMON, bandwidth management, port mirroring, and warning by email or relay. The ready-to-use Turbo Ring can be set up easily using the web-based management interface, or with the DIP switches located on the top panel of the EDS-405A/408A switches.
