IAGCO2

Air Sensor Module

Carbon Dioxide Sensor Module

Features

Rapid response and recovery time
High stability & long lifespan
Cost efficiency with high performance
Hassle-free :
- On-chip data processing
- No need for external libraries
- No impact on MCU

Download Datasheet

BORN FOR SUPERIOR PERFORMANCE

IAGCO2 is a digital carbon dioxide gas sensor designed for indoor air quality monitoring, security applications, or wireless sensor networks to detect carbon dioxide concentrations near the installation site. This sensor features proven, maintenance-free technology and is engineered for high performance and reliability.

SPECIFICATIONS

Model Name	IAGCO2
Detection	Carbon Dioxide (CO2)
Principle	Non-dispersive Infrared (NDIR)
Measurement Range (ppm)	0 ~ 5000
Resolution (ppm)	1
Accuracy (ppm)	±50±3% of Reading
Response Time (T90) (sec)	<120
Operation Temperature	-10°C ~ 50°C (Ta)
Operation Humidity (%RH)	15 ~ 90
Expected Operating Life	3 Years
Power Supply (V)	VDD : 4.8 ~ 5.2 VDDIO : 3.1 ~ 3.5
Power Consumption (mW)	150
Interface	I²C
Dimension (L x W x H/mm)	37 x 21 x 14

ORDER INFORMATION

P/N	Description
EA3-2AASMM0CI03S4	IAGCO2 CO2 Sensor Module

For more information, please contact our support.
